QBH Automotive Engine Articulation Endoscope with Magnetic Sticker

 QBH Automotive Engine Articulation Endoscope with Magnetic Sticker Product Description

Model	Wireless Inspection Camera
Image Sensor	CMOS Sensor
Effective Pixel	320(H)x240(V)(NTSC);720(H)x625(V)(P)/720(H)x525(V)(N); 720(H)x576(V)(P)/712(H)x480(V)(N)
Focus distance	30mm-80mm
View angle	60 degree Fov(D)
Probe diameter	Φ3.9/Φ5.5/Φ9.0/Φ10/Φ17 mm;
Probe tube length	1m standard length(up to 20m)
LED illumination	2/4 lamps,illumination can be adjustable in 7 levels
Host
Screen	3.5''TFT LCD QVGA 320 x 240  16.7M color
Signal Transmission	2.4G Wireless Video Transmission,Wired Video Transmission
Record and Photograph	Photo format:JPG/BMP/JPEG
	Video Format:AVI
	Memory card:capacity of 32G mini SD/TF card
Input Voltage	110-220V
Output Voltage	5V-2A
Screen Battery	Built-in Li-battery 1200MAH 3.7V
Working Voltage	5V
Working Current	600MA/H
Handle Battery	4X AA Alkaline Battery

  Packaging & Shipping

Package Dimension	Color box:400*300*60mm; 10pcs/carton
	Toolbox:450*365*130mm; 3pcs/carton

 Our Services 1. We are a professioal manufacturer of Video endoscope,4-way articulation Borescope,Usb Borescope,WiFi Endoscope,90° side automotive engine endoscope. 2. We can provide ODM and OEM service according to your requirements. 3. Any question,you can contact us at any time.  Company Information
 Shenzhen QBH Technology Development Co.,Ltd is seized of R&D,manufacturing,international trading three in one high technology developing enterprise.QBH is a professional manufacturer of video borescope,industrial endoscope,inspection camera for several years in Shenzhen,China.QBH Three Strong Features: 1.    Professional OEM/ODM services are available, provide help for Emerson(USA) to develop the new endoscope inspection camera head.2.     Possess of more than 10 Patent products,such as we design and develop 4-Ways articulating electronic control video inspection system and HD USB magnification Manual Focusing endoscope.3.    Providing Customized Service such as various camera head with different dimension and length, even metal coupling connectors. FAQ 1.Q: Endoscope questioon:What mode of payment do you support?    A: We support these mode of payment such as:Paypal,TT,L/C,Western Union. According to your specific circumstances,you can choose the most suitable mode of payment. 2.Q: Endoscope question:What's length of the snake tube?    A: The standard tube length is 1M.The tube can be made up to 10M.We can provide ODM and OEM service according to your requirements. 3.Q: Endoscope question:How long time can the host and the screen keep working?    A: The screen can keeping working for 1 hours.The host can keep working for 6 hours.The screen charger time is 4-6 hours. 4.Q: Endoscope question:Is the snake tube detachable?Is the host removable from the screen?    A: The tube is detachable.The host can be removed from the screen.The screen can keep working when separated from host within 10 M. Trade Shows QBH have already taken part in several times of HKTDC Electronics Fair(Spring/Autumn) from Spring of 2012. We will go on to have the show in the future. We are sincerely welcome your visiting!

Contact us if you need more details on Automotive Engine Endoscope. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Pipe Inspection Camera、Handheld Wireless Camera. If these products fail to match your need, please contact us and we would like to provide relevant information.

Product Categories : WIFI & USB Series > Wireless Borescope
